General Description The M18 Dromader is designed for ag air operation of large fields areas and forest-, bush-, and crop fire fighting. M18 has been type-certificated by 15 foreign airworthiness authorities, including the USA (FAA), Canadian, Australian, Brazilian, EASA (EASA.A.056) and others. The PZL-Mielec M-18 Dromader (Polish: 'Dromedary') is a single engine agricultural aircraft that is manufactured by PZL-Mielec in Poland. The aircraft is used mainly as a cropduster or firefighting machine. 1 Development 2 Variants 3 Operators 3.1 Military 3.2 Civil 4 Specifications (M18B Dromader) 5 See also 6 References 7 External links PZL-Mielec, then known as WSK-Mielec, began to design.

The PZL-Mielec M-18 Dromader (Polish: 'Dromedary') is a single engine agricultural aircraft that is manufactured by PZL-Mielec in Poland. The aircraft is used mainly as a cropduster or firefighting machine.

Development

PZL-Mielec, then known as WSK-Mielec, began to design the Dromader in the mid 1970s, with help of United States aircraft manufacturer Rockwell International. PZL-Mielec asked for Rockwell's help because of the political situation at the time: operating in an Eastern Bloc country, PZL wanted the aircraft to sell well worldwide, and the company realized that FAA certification would be important in reaching that goal. Rockwell on the other hand wanted to fit Polish high-power radial engines into its agricultural planes. As a result of this cooperation the Rockwell Thrush Commander aircraft was fitted with the PZL-3 engine, and the Polish designers created the higher payload M-18 Dromader by introducing the more powerful ASz-62 engine, making structural changes to the airframe, and increasing dimensions. This co-operation meant that the Dromader shares outer wing panels and part of a fuselage with the Thrush Commander.

The first prototype of the aircraft flew on August 27, 1976. In September 1978, the aircraft was given certification to fly in Poland. Certifications from many countries around the world followed soon.

Many aircraft of the M-18 type and its variations can still be seen around the world. They were sold to 24 countries, 200 are used in the USA.

Most Dromaders are easy to distinguish because of their yellow color. Over 740 had been built by 2006. Currently (2006) models M-18B and M-18BS are offered by PZL-Mielec.

Variants

• M-18 - original one-seat production version, now available for special orders only.
• M-18A - two seater available from 1984 onwards. Allows a mechanic or chemical loader to be carried as a passenger to remote fields.
  • M-18AS - two-cockpit trainer version
• M-18B - refined version of M-18A with increased capacity, flown in 1993.
  • M-18BS - two-cockpit trainer.
• M-18C - version with more powerful 895 kW (1,200 hp) Kalisz K-9 engine. Flown in 1995 but not produced.
• M-18/T45 Turbine Dromader - turboprop powered with Pratt & Whitney Canada PT6A-45 engine. First flew in 1985 and was given FAA certification in April 1986.
• M-21 Dromader Mini - smaller variant (1100 kg of chemicals), flown in 1982, not produced.
• M-24 Dromader Super - bigger variant (2000 kg of chemicals), flown in 1987, not produced.
• M-25 Dromader Mikro - smaller variant (500 kg of chemicals), sketch only.

Operators

M18 Dromader Flight Manual User

Argentina

Australia

• AGA Services
• Dunn's Aviation
• Leafair
• Northhampton Holdings
• Woorayl Air Services

Bulgaria

• Fortuna Air

Canada

• Epandair Inc.
• Supermarine Aircraft Inc.

Chile

• Alas Agricolas
• Corporación Nacional Forestal operates at least two aircraft.

China

Czech Republic

• Agroair
• Air Special
• Beta Air

Germany

Greece

Hungary

Italy

Morocco

Montenegro

Nicaragua

Poland

• Aeroklub Polski
• Lasy Państwowe
• Zakład Usług Agrolotniczych

Serbia

• JAT Privredna Avijacija

South Africa

• Birdog Aviation

Spain

• Avialsa
• Tratamientos Aereos Martinez Ridao

Turkey

United States

• Downstown Aero Group Service
• South Dakota operates aircraft for wildland fire suppression.
• Valley Air Service
• Western Pilot Service

Venezuela

Specifications (M-18B Dromader)

Data from Jane's All The World's Aircraft 2003–2004^[1]

General characteristics

• Crew: one, pilot
• Capacity: one passenger, and up to 2,500 L (660 US gallons) or 2,200 kg (4,850 lb) of chemicals
• Length: 9.47 m (31 ft 1 in)
• Wingspan: 17.70 m (58 ft 0¾ in)
• Height: 3.70 m (12 ft 1¾ in)
• Wing area: 40.00 m² (430.5 ft²)
• Airfoil: NACA 4416 at root, 4412 on outer wings
• Empty weight: 2,710 kg^[2] (5,975 lb)
• Max takeoff weight: 5,300 kg (11,700 lb)
• Powerplant: 1 × WSK 'PZL-Kalisz' ASz-62IR piston radial, 731 kW (980 hp)

Performance

• Never exceed speed: 280 km/h (151 knots, 174 mph)
• Maximum speed: 230 km/h (124 knots, 143 mph)
• Stall speed: 108 km/h (59 knots, 68mph) (flaps down)
• Range: 970 km (523 nmi, 602 miles)
• Service ceiling: 6,500 m (21,320 ft)
• Rate of climb: 6.5 m/s (1,280 ft/min)

See also

Related development

• Rockwell Thrush Commander
• PZL M-24 Dromader Super


Aircraft of comparable role, configuration and era

• Zlin Z-37 Cmelak


References

1. ^ Jackson 2003, pp. 338–339.
2. ^ Taylor 1999, p.450. (M-18A)

• Jackson, Paul. Jane's All The World's Aircraft 2003–2004. Coulsdon, UK: Jane's Information Group, 2003. ISBN 0-7106-2537-5.
• Taylor, Michael J. H. Brassey's World Aircraft & Systems Directory 1999/2000. London: Brassey's, 1999. ISBN 1 85753 245 7.
